TP Link TL-LS109P 9-Port 10/100Mbps Desktop Switch with 8-Port PoE+

TP-Link TL-LS109P 9-Port 10/100Mbps Desktop Switch with 8-Port PoE+

Reliable Power and Data Connectivity for Professional Networks

The TP-Link TL-LS109P is a compact and efficient 9-Port Fast Ethernet Desktop Switch equipped with 8 PoE+ ports, specifically engineered to power and connect multiple network devices with ease. Offering high performance, plug-and-play convenience, and robust power management, it’s the ideal solution for small offices, IP surveillance, and smart home networks.

Power over Ethernet Plus (PoE+) Support

The TL-LS109P supports Power over Ethernet Plus (PoE+) on ports 1–8, allowing each port to deliver up to 30 W per device and a total PoE power budget of up to 65 W. This makes it ideal for powering high-demand devices such as IP cameras, access points, and VoIP phones, all through a single Ethernet cable for both data and power.

Automatic Power Management

With intelligent power management, the switch automatically detects power consumption and protects against overload, overcurrent, and short-circuit issues. When total power demand exceeds 65 W, it intelligently prioritizes critical devices to maintain continuous network operation.

Plug & Play Simplicity

Setup is effortless — simply plug in your Ethernet cables and power up. The TL-LS109P automatically detects connected devices and manages connections without requiring any software installation or configuration.

Reliable Fast Ethernet Connectivity

Equipped with 9× 10/100 Mbps RJ45 ports, including 8 PoE+ ports and 1 uplink port, this switch ensures smooth, stable, and efficient data transmission across your network. Perfect for small-scale deployments or extensions of existing wired systems.

Durable Metal Housing

Built with a high-quality metal enclosure, the TL-LS109P ensures long-term durability and excellent heat dissipation. Its solid construction supports consistent operation in demanding office or industrial environments.

Silent Fanless Operation

The fanless design provides quiet and stable performance, making this switch perfect for noise-sensitive locations such as offices, shops, or residential areas.

Energy-Efficient Operation

Powered by TP-Link Green Ethernet technology, the TL-LS109P intelligently adjusts power consumption based on cable length and link status, reducing energy usage by up to 80% without sacrificing performance.

Efficient Data Transmission

The switch supports IEEE 802.3x flow control for full-duplex mode and backpressure for half-duplex mode, ensuring smooth and reliable data flow even during heavy traffic.

Flexible Deployment

Its compact and durable design allows for both desktop and wall-mounted installation, making it easy to integrate into different network setups — from security monitoring to office networks.

Key Features

• 9× Fast Ethernet ports with 8× PoE+ for flexible connections

• PoE power budget up to 65 W for powering multiple devices

• Plug & Play — no setup required

• Intelligent power management for safe operation

• Durable metal body for long-lasting reliability

• Silent, fanless design suitable for quiet environments

• IEEE 802.3x flow control ensures stable data transmission

• Green Ethernet technology for reduced energy consumption

• Desktop or wall-mount installation flexibility
